The articulated robot that transforms itself

Working area: 800 m2
Perimeter wire: Yes
Maximum slope: 35%
Charge: Automatic - Contact
Connection Bluetooth
Cutting Height Adjustment Manual

Power unit MEDIUM

Working area: 1200 m2

Charge: Contact

Working time: 03:00h

Battery: 1x6.9Ah

Power Unit PREMIUM

Working area: 1800 m2

Charge: Contact

Working time: 04:00h

Battery: 1x10,35Ah

find specialised centre Find specialised centre

The B X4 model is ideal for those who require a simple, reliable robot that can adapt to changes. Its flexible yet solid and safe structure enables the installation of three different types of Power Units, that allow it to be converted from a robot for small to medium-sized gardens (with Power Unit Light up to 1,000 sqm or with Power Unit Medium up to 1,400 sqm) to a solution that covers up to 2,200 sqm (with Power Unit Premium) with extreme accuracy. The brushless motors, rubber profile wheels and soft bumpers complete the characteristics of an innovative robot that meets all sort of needs. Equipped with a Bluetooth Receiver that can be independently controlled by a dedicated APP. Its new design also allows greater autonomy: with a deck engineered around the blade, it provides quick and safe self-cleaning.

Flex rubber rear wheel

Uneven terrains

Central joint

Technical datasheet

Maximum cutting surface [m²] (-20%)* 800 m2 1200 m2 1800 m2
Motor type BrushlessBrushlessBrushless
Lithium-Ion battery (25.9V) 1x3.45Ah1x6.9Ah1x10,35Ah
Allowable slope (%) 45%45%45%
Maximum slope (%) 35%35%35%
Slope on outer edge or perimeter wire (%) 20%20%20%
Average working time [h](+-20%) 01:3003:0004:00
Charging mode AutomaticAutomaticAutomatic
Charging type Contact Contact Contact

Blade type 4-point start
Cutting width [cm] 25
Cutting height (min-max) [mm] 20-65
Cutting Height Adjustment Manual
Spiral cutting method Yes
"SDM" cutting method No
Pre-Set Path cutting method -
"+ Infinity" cutting method No
Navigation GPS - RTK -
Self-levelling traction Yes
Eco mode Yes
Rain sensor Yes
Drop off sensor -
Ultrasound obstacol detection No
AI grass sensor -
Virtual Areas 8
Lawn areas that can be managed including the main one 8

User interface Keypad & LED
Control APP Bluetooth
Bluetooth receiver Yes
GPS-GSM remote control (ZCS Connect) On request
Integration with "Smart Assistant" voice assistants Included in ZCS Connect
AMICO On request
ZDefence On request

Security PIN PIN code via APP

Robot weight - incl. batteries [kg] 15.0 15.3 15.6
Robot dimensions (lxwxh) 474x663x330 mm 474x663x330 mm 474x663x330 mm
Wheel profile Flex rubberFlex rubberFlex rubber
Noise level [dB(A)] 636363
Protection rating IPx5IPx5IPx5

Robot dimensions (lxwxh) 474x663x330 mm

  • Fixing pegs (20 pcs)
  • Charging station
  • User manual

Documentation & Video Tutorials



  • Next generation processors
  • App Bluetooth
  • Smart batteries
  • Self-cleaning
  • Keypad & LED
  • Bumper and soft obstacle sensor
  • 25 cm blade


  • BASE 4 0 4 36 QUAD
    Garage cover colour glossy black

    The cover is designed to protect the robot from UV rays and weather during charging.

    ZDEFENCE (anti-mosquito device)

    The natural, simple and effective defence system against mosquitoes. The use of a natural biorepellent contained in the dispenser installed on the moving robot will make your garden welcoming and liveable, even at dusk.


2 years warranty (covering the conditions and limitations stated in the warranty booklet) + 4 years extension

To validate the warranty extension, it is mandatory to carry out regular winter servicing, to register such servicing on the manufacturer’s website, to request the issuing and the appropriate filing of the relative, duly-completed certifications.
